NETGEAR C6300 User Manual

Specify Initial Settings
20
AC1750 WiFi Cable Modem Router
View Modem Router Initialization
You can track the initialization procedure of the modem router, and get details about the
downstream and upstream cable channel. The time is displayed after the modem router is
initialized.
The modem router automatically goes through the following steps in the provisioning
process:
1. Scans and locks the downstream frequency and then ranges the upstream channels.
2. Obtains a WAN address for the modem router.
3. Connects to the Internet.
 To view the status of the modem router initialization:
1. Launch a web browser from a computer or wireless device that is connected to the
network.
2. T
ype http://routerlogin.net or http://192.168.0.1.
A login screen displays.
3. Enter the modem router user name and password.
The user name is admin
.
The default password is password.
The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Select Cable Connection.
The Startup Procedure section displays the initialization progress.
The Downstream Bonded Channels section displays the status of each channel.

NETGEAR C6300 Specifications

General

DSL WAN	Yes
Ethernet WAN	-
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	450 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Processor frequency	600 MHz
Cables included	LAN (RJ-45)
Product type	Tabletop router
Product color	Black
Power source type	DC

Weight and Dimensions

Depth	174 mm
Width	277.9 mm
Height	75.18 mm
Weight	690 g
