NETGEAR EAX14 User Manual

•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/
or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 65.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon
, click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
6. In the 2.4 GHz or 5 GHz Network section, type a new network name in the Network
Name (SSID) field.
7. Click the SAVE button.
Your settings are saved.
Turn off the SSID broadcast to create a
hidden network
By default, the extender broadcasts its WiFi signal so that its WiFi network names (SSIDs)
are easy for you to find and connect to from your computer, tablet, or smartphone. You
can turn off the SSID broadcast to create a hidden WiFi network. To connect to a hidden
network you must know its SSID and password and manually enter them.
To turn off the SSID broadcast to create a hidden network:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
User Manual30Extender Network Settings
AX1800 4-Stream WiFi 6 Mesh Extender

NETGEAR EAX14 Specifications

Operating Environment

operating temperature	32° to 104°F (0° to 40°C)
operating humidity	90% maximum relative humidity, noncondensing

Ports & interfaces

ethernet port speed	10/100/1000 Mbps
wireless standards	802.11a/b/g/n/ac/ax and 802.11k

Weight and Dimensions

dimensions	5.9 x 2.7 x 2.1 in (149.86 x 68.58 x 53.34 mm)
weight	0.49 lb (222 g)
