NETGEAR EAX20 User Manual

Change the WiFi speed
When the extender's 2.4 GHz WiFi backhaul is connected to the root access point (root
AP), the extender's 2.4 GHz fronthaul WiFi speed is the same as the root AP's 2.4 GHz
WiFi speed. The extender cannot change its 2.4 GHz WiFi speed.
This also applies to the extender's 5 GHz WiFi speed. When the extender's 5 GHz WiFi
backhaul is connected to the root AP, the extender's 5 GHz fronthaul WiFi speed is the
same as the root AP's 5 GHz WiFi speed. The extender cannot change its 5 GHz WiFi
speed.
The following table further explains whether if the extender's 2.4 GHz or 5 GHz WiFi
speed is changeable based on which extender backhaul connection is used to connect
to the root AP.
Table 9. Extender backhaul and fronthaul WiFi connection
Is the extender's 5 GHz
fronthaul WiFi speed
changeable?
Is the extender's 2.4
GHz fronthaul WiFi
speed changeable?
Which extender WiFi
backhaul is connected
to the root AP?
NoNoBoth 2.4 GHz and 5 GHz
YesNo2.4 GHz only
NoYes5 GHz only
YesYesNo connection
To change the extender's WiFi speed:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 60.
User Manual31Extender Network Settings
AX1800 4-Stream WiFi Mesh Extender

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
