NETGEAR EAX20 User Manual

Factory Default Settings
To reset the extender to factory default settings, you can use the Reset button on the
side panel or you can log in and click the onscreen RESET button. For more information,
see Return the extender to its factory default settings on page 51.
The following table shows the factory default settings.
Table 10. Factory default settings
Default SettingsFeature
EnabledSmart Setup
EnabledWiFi communication
NETGEAR_EXTWiFi network name (SSID)
DisabledSecurity
Auto
1
Transmission speed
Varies by regionCountry/region
802.11a/b/g/n/ac/axOperating mode
Max 600 MbpsData rate in the 2.4 GHz band
Disabled by default
(When enabled the max data rate is 1200 Mbps)
Data rate in the 5 GHz band
Server and client are enabledDHCP
1
Maximum WiFi signal rate (IEEE Standard 802.11). Actual throughput can vary. Network conditions and environmental
factors, including volume of network traffic, building materials and construction, and network overhead lower actual
data throughput rate.
User Manual65Supplemental Information
AX1800 4-Stream WiFi Mesh Extender

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
