Page #62 background imageLoading...
Page #62 background image
To run Smart Setup again, click the YES button. To manually configure the extender,
click the NO, CONFIGURE MANUALLY button.
Cannot access mywifiext.net
When you try to access http://www.mywifiext.net/ to set up your extender, you might
receive an error message that says you are not connected to the extender's WiFi network.
This website is not a regular Internet website. It is a local web address used to log in to
the extender web interface and view the extender settings.
Your computer or mobile device must be connected to your extender network to access
http://www.mywifiext.net/.
Try these troubleshooting tips to connect to http://www.mywifiext.net/:
If you’re trying to access http://www.mywifiext.net/ for the first time to set up your
extender, see Connect with the NETGEAR installation assistant on page 17 and follow
the instructions.
Launch a web browser and enter the extender’s default IP address, which is
192.168.1.250.
If this IP address does not work, it is possible that your extender’s IP address might
have changed. You can log in to your router to view your extender’s IP address. For
more information, see Find the Extender’s IP address on page 60.
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender’s IP address, see Find the
Extender’s IP address on page 60.
Clear your web browser’s cache and browsing history and try again.
For more information, see the help content for your web browser.
Try using another web browser.
Assign a static IP address to your computer.
Before you change any network settings, note your current Default gateway (Windows)
or Router (Mac) address. Use the IP address 192.168.1.249 and the subnet mask
255.255.255.0.
For more information, see your computer’s documentation.
User Manual62FAQs and troubleshooting
AX1800 4-Stream WiFi Mesh Extender

Table of Contents

Other manuals for NETGEAR EAX20

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR EAX20 and is the answer not in the manual?

NETGEAR EAX20 Specifications

General IconGeneral
TypeNetwork repeater
WPS push buttonYes
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum transfer distance- m
Package typeBox
Package depth290 mm
Package width210 mm
Package height110 mm
Package weight990 g
Master (outer) case width242 mm
Master (outer) case height380 mm
Master (outer) case length477 mm
Master (outer) case weight5370 g
Quantity per master (outer) case4 pc(s)
Modulation1024-QAM
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Cabling technology10/100/1000Base-T(X)
Security algorithms128-bit AES, WPA-PSK
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports4
Product colorBlack
Weight and Dimensions IconWeight and Dimensions
Depth169.5 mm
Width241.7 mm
Height63.4 mm
Weight504.5 g
