NETGEAR EAX20 User Manual

Technical and Environmental Specifications
The following table shows the technical and environmental specifications.
Table 11. Technical specifications
Technical Specifications
Data and routing protocols: TCP/IP, DHCP server and client, DNS relayNetwork protocol and
standards compatibility
•
Dimensions: 9.5 x 6.7 x 2.5 in (241.7 x 169.5 x 63.4 mm)
•
Weight: 1.1 lb (504.4 g)
Physical specifications
•
Operating temperature: 32° to 104°F (0° to 40°C)
•
Operating humidity: 90% maximum relative humidity, noncondensing
Environmental
•
Local: Four 10/100/1000 Mbps Ethernet ports
•
802.11a/b/g/n/ac/ax and 802.11k
Interface
User Manual66Supplemental Information
AX1800 4-Stream WiFi Mesh Extender

NETGEAR EAX20 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Package type	Box
Package depth	290 mm
Package width	210 mm
Package height	110 mm
Package weight	990 g
Master (outer) case width	242 mm
Master (outer) case height	380 mm
Master (outer) case length	477 mm
Master (outer) case weight	5370 g
Quantity per master (outer) case	4 pc(s)
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	128-bit AES, WPA-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n
Ethernet LAN (RJ-45) ports	4
Product color	Black

Weight and Dimensions

Depth	169.5 mm
Width	241.7 mm
Height	63.4 mm
Weight	504.5 g
