NETGEAR GS110EMX User Manual

The login page of the local browser interface opens.
7. Enter the switch password.
The default password is password. The password is case-sensitive.
The Switch Information page displays. The page shows the IP address that is assigned
to the switch.
Tip: You can copy and paste the IP address into a new shortcut or bookmark it for
quick access on your computer or mobile device. However, if you restart the switch,
a dynamic IP address (assigned by a DHCP server) might change and the bookmark
might no longer link to the login page for the switch. In that situation, you must
repeat this procedure so that you can discover the new IP address of the switch in
the network and update your bookmark accordingly. You can also set up a fixed
(static) IP address for the switch (see Set Up a Fixed IP Address for the Switch on
page 21) to make sure that the new bookmark always links to the login page for the
switch, even after you restart the switch.
Access the Switch From a Mac or Windows-Based Computer
Using the NETGEAR Switch Discovery Tool
The NETGEAR Switch Discovery Tool lets you discover the switch in your network and
access the local browser interface of the switch from a Mac or a 64-bit Windows-based
computer. If your Mac does not support Bonjour, use the following procedure.
To install the NETGEAR Switch Discovery Tool, discover the switch in your network,
access the switch, and discover the switch IP address:
1. Download the Switch Discovery Tool by visiting
netgear.com/support/product/gs110emx.aspx#download.
Depending on the computer that you are using, download either the Mac version
or the version for a 64-bit Windows-based computer.
2.
Temporarily disable the firewall, Internet security, antivirus programs, or all of these
on the computer that you use to configure the switch.
3.
Unzip the Switch Discovery Tool files, click or double-click the Setup.exe file (for
example, NetgearSDT-V1.1.115_Win_x64_Setup.exe), and install the program
on your computer.
Depending on your computer setup, the installation process might add the NETGEAR
Switch Discovery Tool icon to the Dock of your Mac or the desktop of your
Windows-based computer.
4. Reenable the security services on your computer.
User Manual19Install and Access the Switch in
Your Network
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX

NETGEAR GS110EMX Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN, Tagged VLAN, Port-based VLAN
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
DHCP features	DHCP client
Queue scheduling algorithms	Weighted Round Robin (WRR)
Noise level	0 dB
Power connector	DC-in jack
Installed SFP modules quantity	0
Gigabit Ethernet (copper) ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	10
Jumbo frames	10240
Forwarding rate	41.664 Mpps
Latency (1 Gbps)	4 µs
Latency (10 Gbps)	3 µs
MAC address table	16000 entries
Packet buffer memory	0.128 MB
Latency (10-100 Mbps)	7 µs
Number of multicast groups filtered	128
Safety	UL/cUL Listed (UL 60950-1)/CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, SubpartB, Class B ICES-003:2016 Issue 6, Class B ANSI C63.4:2014 N 55032:2012 +AC:2013 / CISPR 32:2012 / AS/NZS CISPR 32:2013, Class B EN 55032:2015 +AC:2016 / CISPR 32:2015 +COR1:2016 / AS/NZS CISPR 32:2015, Class B EN 61000-3-2:2014 EN 61000-3-3:2013 EN 55024:2010 +A1:2015
Product color	Black
LED indicators	Link, Power, Speed
Number of fans	0 fan(s)
Housing material	Metal
Electromagnetic compatibility	Class B
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	15.6 W
Power consumption (typical)	6.6 W
Heat dissipation	53.35 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Package depth	270 mm
Package width	164 mm
Package height	85 mm
Package weight	1340 g
Shipping (inner) case width	490 mm
Shipping (inner) case height	339 mm
Shipping (inner) case length	391 mm
Shipping (inner) case net weight	15460 g
Number of layers per pallet (air)	4 pc(s)
Number of cartons per pallet layer	6 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	102 mm
Width	236 mm
Height	27 mm
Weight	750 g
