The default password is password. The password is case-sensitive.
The Switch Information page displays.
5.
Select System > LAG > LAG Membership.
The LAG Membership page displays.
6.
In the LAG ID menu, select the LAG ID.
You can select a LAG ID from 1 to 5.
7.
Enter a name in the LAG Name field.
You can enter a name of up to 15 printable ASCII characters, including a blank space
and special characters such as !, @, #, and $.
8.
Select the ports for the LAG by selecting the check boxes that are associated with
the port numbers.
A LAG consists of at least two ports.
9.
Click the Apply button.
Your settings are saved.
10.
To enable the LAG for which you just set up the port membership, do the following:
a.
Select System > LAG > LAG Configuration.
The LAG Configuration page displays.
b.
Select the LAG ID of the LAG for which you just set up the port membership.
c.
In the Admin Mode menu, select Enable.
d.
In the LAG Type menu, select Static.
The Port Member field for the selected LAG ID shows the ports that you selected
in Step 8.
The LAG Status field for the selected LAG ID shows whether the LAG is established
(Up) or not established (Down).
e.
Click the Apply button.
Your settings are saved.
Set Up a Link Aggregation Control Protocol Group
The switch can support five LAGs, which can be a combination of Link Aggregation
Control Protocol (LACP) groups and static link aggregation groups.
User Manual57Manage Network Settings
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX
