Page #79 background imageLoading...
Page #79 background image
Basic Technical Specifications
The following table shows the basic technical specifications of the switch.
For more specifications, see the data sheet that you can download by visiting
downloadcenter.netgear.com.
Table 7. Basic technical specifications
DescriptionFeature
IEEE 802.3 Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5GBASE-T and 5GBASE-T
IEEE 802.3an 10GBASE-T
IEEE 802.3i 10BASE-T
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
IEEE standards
Eight RJ-45 ports (ports 1 through 8) that support 1000BASE-T, 100BASE-TX, or
10BASE-T
Two RJ-45 ports (ports 9 and 10) that support 10GBASE-T, 5GBASE-T, 2.5GBASE-T,
1000BASE-T, or 100BASE-TX
Network interfaces
For 100 Mbps, use a Category 5 (Cat 5) or higher rated cable.Network cable
For 1 Gbps, 2.5 Gbps, or 5 Gbps, use a Category 5e (Cat 5e) or higher rated cable.
For 10 Gbps for up to 55 meter (180 feet), use a Category 6 (Cat 6) or higher rated
cable.
For 10 Gbps for more than 55 meter (180 feet), use a Category 6A (Cat 6A) or higher
rated cable.
The power adapter is localized to the country of sale.
Output: 12V, 2.5A
Power adapter
15.6WMaximum power
consumption
9.29 x 4.02 x 1.06 in. (236 x 102 x 27 mm)Dimensions (W x D x H)
1.65 lb (0.75 kg)Weight
32º to 104ºF (0° to 40°C)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
10,000 ft (3,000 m) maximumOperating altitude
–4° to 158°F (–20º to 70ºC)Storage temperature
User Manual79Factory Default Settings and
Technical Specifications
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX

Table of Contents

Other manuals for NETGEAR GS110EMX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR GS110EMX and is the answer not in the manual?

NETGEAR GS110EMX Specifications

General IconGeneral
Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes
Number of VLANs64
Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3az, IEEE 802.3x
Virtual LAN featuresVoice VLAN, Tagged VLAN, Port-based VLAN
Cable types supportedCat5, Cat5e, Cat6, Cat6a, Cat7
DHCP featuresDHCP client
Queue scheduling algorithmsWeighted Round Robin (WRR)
Noise level0 dB
Power connectorDC-in jack
Installed SFP modules quantity0
Gigabit Ethernet (copper) ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity10
Jumbo frames10240
Forwarding rate41.664 Mpps
Latency (1 Gbps)4 µs
Latency (10 Gbps)3 µs
MAC address table16000 entries
Packet buffer memory0.128 MB
Latency (10-100 Mbps)7 µs
Number of multicast groups filtered128
SafetyUL/cUL Listed (UL 60950-1)/CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable-
Certification47 CFR FCC Part 15, SubpartB, Class B ICES-003:2016 Issue 6, Class B ANSI C63.4:2014 N 55032:2012 +AC:2013 / CISPR 32:2012 / AS/NZS CISPR 32:2013, Class B EN 55032:2015 +AC:2016 / CISPR 32:2015 +COR1:2016 / AS/NZS CISPR 32:2015, Class B EN 61000-3-2:2014 EN 61000-3-3:2013 EN 55024:2010 +A1:2015
Product colorBlack
LED indicatorsLink, Power, Speed
Number of fans0 fan(s)
Housing materialMetal
Electromagnetic compatibilityClass B
Output current2.5 A
Output voltage12 V
Power consumption (max)15.6 W
Power consumption (typical)6.6 W
Heat dissipation53.35 BTU/h
Operating altitude0 - 3000 m
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)0 - 90 %
Package depth270 mm
Package width164 mm
Package height85 mm
Package weight1340 g
Shipping (inner) case width490 mm
Shipping (inner) case height339 mm
Shipping (inner) case length391 mm
Shipping (inner) case net weight15460 g
Number of layers per pallet (air)4 pc(s)
Number of cartons per pallet layer6 pc(s)
Quantity per shipping (inner) case10 pc(s)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth102 mm
Width236 mm
Height27 mm
Weight750 g
