10.
(Optional) Select an option from the IGMP Snooping Static Router Port menu.
You can select a port to be the dedicated IGMP snooping static router port if no
IGMP query exists in the network for the switch to discover the router port
dynamically. After a port is selected as the static router port, all IGMP Join and Leave
reports are forwarded to the port.
11.
Click the Apply button.
Your settings are saved.
Specify a VLAN for IGMP Snooping
You can specify a VLAN for IGMP snooping only if you enabled port-based or
802.1Q-based VLANs (see Use VLANS for Traffic Segmentation on page 29).
To specify a VLAN for IGMP snooping:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that
is off-network using an Ethernet cable.
2. Launch a web browser.
3.
In the address field of your web browser, enter the IP address of the switch.
The login page displays.
4. Enter the switch password.
The default password is password. The password is case-sensitive.
The Switch Information page displays.
5.
Select System > Multicast.
The IGMP Snooping Configuration page displays.
6.
Make sure that the IGMP Snooping Status Enable radio button is selected.
By default, the Enable radio button is selected.
7.
In the VLAN ID Enabled for IGMP Snooping field, enter the ID of the VLAN.
By default, if you enable IGMP snooping, snooping occurs on VLAN 1. However, you
can enable snooping on any VLAN:
•
For port-based VLANs, you can enter a VLAN ID from 1 to the maximum number
of ports that the switch supports.
•
For 802.1Q-based VLANs, you can enter a VLAN ID from 1 to 4094.
8.
Click the Apply button.
User Manual55Manage Network Settings
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX
