NETGEAR GS728TPv2 User Manual

Back Panel
The back panel provides a Kensington lock and AC power receptacle. (The switch integrates a fixed, internal
power supply.) The console port is not for customer use.
The following figures show the back panels.
Figure 3. Back panel models GS728TPv2 and GS728TPPv2
Figure 4. Back panel models GS752TPv2 and GS752TPP
Switch Hardware Interfaces
The following sections describe the hardware interfaces on the switch.
RJ-45 Ports for 10/100/1000M BASE-T Ethernet Connectivity
All RJ-45 copper ports support autosensing. When you insert a cable into an RJ-45 port, the switch
automatically ascertains the maximum speed (10 Mbps, 100 Mbps, or 1 Gbps) and duplex mode (half-duplex
or full-duplex) of the attached device. All ports support a Category 5e (Cat 5e) cable (or higher-rated Ethernet
cable) terminated with an 8-pin RJ-45 connector.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink technology.This
technology allows attaching devices to the RJ-45 ports with either straight-through or crossover cables.
When you insert a cable into the switch’s RJ-45 port, the switch automatically performs the following actions:
• Senses whether the cable is a straight-through or crossover cable.
• Determines whether the link to the attached device requires a normal connection (such as when you
are connecting the port to a computer) or an uplink connection (such as when you are connecting the
port to a router, switch, or hub).
• Automatically configures the RJ-45 port to enable communications with the attached device.The Auto
Uplink technology compensates for setting uplink connections while eliminating concern about whether
to use crossover or straight-through cables when you attach devices.
All copper ports also support Power over Ethernet (PoE+).
Hardware Overview
13
24-Port and 48-Port Gigabit PoE+ Smart Managed Pro Switches with 4 SFP Ports

NETGEAR GS728TPv2 Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	24
Total Power over Ethernet (PoE) budget	190 W
MAC address table	16 entries
Packet buffer memory	1.5 MB
Number of static routes	32
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1w, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	226 W
Noise level	27.08 dB
Operating temperature (T-T)	0 - 50 °C
Authentication	Guest VLAN
Authentication type	IEEE 802.1x, TACACS+
MAC address entries	Dynamic MAC address entries
Security algorithms	HTTPS, MD5, SNMP, SNMPv2, SNMPv3, TLS
Queue scheduling algorithms	Weighted Round Robin (WRR)
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Weight and Dimensions

Depth	257 mm
Width	440 mm
Height	43.2 mm
Weight	3780 g
