NETGEAR GS728TPv2 User Manual

Overview
The switch provides twenty-four or forty-eight 10/100/1000BASE-T RJ-45 copper ports that support nonstop
10/100/1000M Layer 2 and Layer 3 networks. All RJ-45 ports support PoE+. Four additional ports can accept
small form-factor pluggable (SFP) gigabit interface converters (GBICs) for 1G fiber or copper connectivity.
For information about application samples, see Applications on page 15.Note
The switch provides administrative management options that let you configure, monitor, and control the
network. Using the local browser–based management interface, you can configure the switch and the
network, including the ports, the management VLAN, VLANs for traffic control, link aggregation for increased
bandwidth, Quality of Service (QoS) for prioritizing traffic, and network security.
Initial discovery of the switch on the network requires the Smart Control Center program, which runs on a
Windows-based computer and is included on the resource CD. If you do not use a Windows-based computer,
get the IP address of the switch from the DHCP server in the network or use an IP scanner utility.
After discovery, you can configure the switch using the local browser interface for advanced setup and
configuration of features, or the Smart Control Center program for very basic setup. For more information,
see the user manual, which you can download from downloadcenter.netgear.com.
You can install the switch freestanding or rack mounted in a wiring closet or equipment room. The switch
is IEEE compliant and offers low latency. All ports can automatically negotiate to the highest speed, which
makes the switch very suitable for a mixed environment with Fast Ethernet and Gigabit Ethernet.
Use Category 5e (Cat 5e) or higher-rated Ethernet cables terminated with RJ-45 connectors to make Gigabit
connections.
Features
The switch supports the following key hardware features:
• 24 or 48 PoE+ Gigabit Ethernet ports.
• 4 dedicated SFP ports for 1000BASE-SX, 1000BASE-LX, and 1000BASE-T connectivity.
• PoE+ support:
- 24 or 48 PoE+ (802.3at) ports
- Total PoE+ power budget of 190W (model GS728TPv2), 380W (models GS728TPPv2 and
GS752TPv2), or 760W (model GS752TPP)
• MAC table size of 16K.
• Variable speed fan that can lower the noise level during low temperatures.
• Acoustic noise (measured at 25°C) is equal to or less than 31 dBA (model GS728TPv2), 35 dBA (model
GS728TPPv2), 38 dBA (model GS752TPv2), or 43 dBA (model GS752TPP).
• 56 Gbps (models GS728TPv2 and GS728TPPv2) or 104 Gbps (models GS752TPv2 and GS752TPP)
full-duplex, nonblocking switch fabric.
Introduction
5
24-Port and 48-Port Gigabit PoE+ Smart Managed Pro Switches with 4 SFP Ports

NETGEAR GS728TPv2 Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	24
Total Power over Ethernet (PoE) budget	190 W
MAC address table	16 entries
Packet buffer memory	1.5 MB
Number of static routes	32
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1w, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	226 W
Noise level	27.08 dB
Operating temperature (T-T)	0 - 50 °C
Authentication	Guest VLAN
Authentication type	IEEE 802.1x, TACACS+
MAC address entries	Dynamic MAC address entries
Security algorithms	HTTPS, MD5, SNMP, SNMPv2, SNMPv3, TLS
Queue scheduling algorithms	Weighted Round Robin (WRR)
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Weight and Dimensions

Depth	257 mm
Width	440 mm
Height	43.2 mm
Weight	3780 g
