NETGEAR GS728TPv2 User Manual

1
Introduction
This hardware installation guide is for the following NETGEAR Smart Managed Pro Switches:
• 24-Port Gigabit PoE+ Smart Managed Pro Switch with 4 SFP Ports, Model GS728TPv2
• 24-Port Gigabit PoE+ Smart Managed Pro Switch with 4 SFP Ports, Model GS728TPPv2
• 48-Port Gigabit PoE+ Smart Managed Pro Switch with 4 SFP Ports, Model GS752TPv2
• 48-Port Gigabit PoE+ Smart Managed Pro Switch with 4 SFP Ports, Model GS752TPP
The switch provides twenty-four or forty-eight Gigabit RJ-45 copper PoE+ ports with four dedicated SFP ports.
Power over Ethernet plus (PoE+) lets you provide power to PoE-capable devices such as WiFi access points,
VoIP phones, and IP security cameras so that you do not need to use power supplies for those devices. The
maximum PoE+ (IEEE 802.3at) power that the switch can provide across all active PoE+ ports depends on the
model: 190W for model GS728TPv2, 380W for models GS728TPPv2 and GS752TPv2, and 760W for model
GS752TPP.
This hardware installation guide complements the installation guide that came with your switch.The resource
CD that came with your switch includes software and additional documentation and support resources.
This chapter serves as an introduction to the switch and includes the following sections:
• Overview
• Features
• Safety Instructions and Warnings
For more information about the topics that are covered in this manual, visit the support website
at support.netgear.com.
Note
For technical specifications, see the data sheet at
netgear.com/business/products/switches/managed. For switch documentation, see the
resource CD in the product package or visit downloadcenter.netgear.com.
Note
4

NETGEAR GS728TPv2 Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	24
Total Power over Ethernet (PoE) budget	190 W
MAC address table	16 entries
Packet buffer memory	1.5 MB
Number of static routes	32
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1w, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	226 W
Noise level	27.08 dB
Operating temperature (T-T)	0 - 50 °C
Authentication	Guest VLAN
Authentication type	IEEE 802.1x, TACACS+
MAC address entries	Dynamic MAC address entries
Security algorithms	HTTPS, MD5, SNMP, SNMPv2, SNMPv3, TLS
Queue scheduling algorithms	Weighted Round Robin (WRR)
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Weight and Dimensions

Depth	257 mm
Width	440 mm
Height	43.2 mm
Weight	3780 g
