NETGEAR GS728TPv2 User Manual

Troubleshooting Chart
The following table lists symptoms, possible causes, and possible solutions for problems that might occur.
Table 4.Troubleshooting chart
Possible SolutionPossible CauseSymptom
Check the power cable connections at the
switch and the power source.
Make sure that all cables are used correctly and
comply with the Ethernet specifications.
Power is not supplied to the switch.Power LED is off.
Check the crimp on the connectors and make
sure that the plug is properly inserted and
locked into the port at both the switch and the
connecting device.
Make sure that all cables are used correctly and
comply with the Ethernet specifications.
Check for a defective port, cable, or module by
testing them in an alternate environment where
all products are functioning.
Port connection is not working.A combined speed and activity
LED or an individual speed LED
and an individual activity LED
are off when the port is
connected to a device.
Break the loop by making sure that only one
path exists from any networked device to any
other networked device. After you connect to
the switch web management interface, you can
configure the Spanning Tree Protocol (STP) to
prevent network loops.
One possible cause is that a
broadcast storm occurred and that a
network loop (redundant path) was
created.
File transfer is slow or
performance is degraded.
Verify that the cabling is correct.
Make sure that all connectors are securely
positioned in the required ports. It is possible
that equipment was accidentally disconnected.
One or more devices are not properly
connected, or cabling does not meet
Ethernet guidelines.
A segment or device is not
recognized as part of the
network.
Break the loop by making sure that only one
path exists from any networked device to any
other networked device. After you connect to
the switch web management interface, you can
configure the Spanning Tree Protocol (STP) to
prevent network loops.
A network loop (redundant path) was
created.
A combined speed and activity
LED or an individual speed LED
and an individual activity LED
are blinking continuously on all
connected ports and the
network is disabled.
Troubleshooting
28
24-Port and 48-Port Gigabit PoE+ Smart Managed Pro Switches with 4 SFP Ports

NETGEAR GS728TPv2 Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	24
Total Power over Ethernet (PoE) budget	190 W
MAC address table	16 entries
Packet buffer memory	1.5 MB
Number of static routes	32
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1w, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	226 W
Noise level	27.08 dB
Operating temperature (T-T)	0 - 50 °C
Authentication	Guest VLAN
Authentication type	IEEE 802.1x, TACACS+
MAC address entries	Dynamic MAC address entries
Security algorithms	HTTPS, MD5, SNMP, SNMPv2, SNMPv3, TLS
Queue scheduling algorithms	Weighted Round Robin (WRR)
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Weight and Dimensions

Depth	257 mm
Width	440 mm
Height	43.2 mm
Weight	3780 g
