NETGEAR GS728TPv2 User Manual

d. Rubber protection caps, which are already installed in the SFP sockets. If you install an SFP
transceiver module, you must remove the cap from the SFP socket.
e. Screws for rack mounting
f. Brackets for rack mounting
g. Installation guide
h. Resource CD with NETGEAR Smart Control Center utility
5. If any item is missing or damaged, contact your local NETGEAR reseller for replacement.
Step 4: Install the Switch
You can install the switch in a standard 19-inch (48.26-centimeter) network equipment rack or on a flat
surface.
Mount the Switch in a Rack
To install the switch in a rack, you need the 19-inch rack-mount kit supplied with the switch.
To install the switch in a rack:
1. Attach the supplied mounting brackets to the side of the switch.
2. Insert the screws provided in the product package through each bracket and into the bracket mounting
holes in the switch.
3. Tighten the screws with a No. 2 Phillips screwdriver to secure each bracket.
4. Align the mounting holes in the brackets with the holes in the rack, and insert two pan-head screws with
nylon washers through each bracket and into the rack.
5. Tighten the screws with a No. 2 Phillips screwdriver to secure the mounting brackets to the rack.
Installation
23
24-Port and 48-Port Gigabit PoE+ Smart Managed Pro Switches with 4 SFP Ports

NETGEAR GS728TPv2 Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	24
Total Power over Ethernet (PoE) budget	190 W
MAC address table	16 entries
Packet buffer memory	1.5 MB
Number of static routes	32
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1w, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	226 W
Noise level	27.08 dB
Operating temperature (T-T)	0 - 50 °C
Authentication	Guest VLAN
Authentication type	IEEE 802.1x, TACACS+
MAC address entries	Dynamic MAC address entries
Security algorithms	HTTPS, MD5, SNMP, SNMPv2, SNMPv3, TLS
Queue scheduling algorithms	Weighted Round Robin (WRR)
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Weight and Dimensions

Depth	257 mm
Width	440 mm
Height	43.2 mm
Weight	3780 g
