Reference Guide for the Model RT311 and RT314 Internet Access Gateway Routers
7-4 Using the Manager Interface for Initial Router Configuration
Using the Manager Interface
Turning on Power to the Router
When power is first applied to the router, several internal tests are performed by the router.
Your Internet line is initialized at this time. During the initialization, the start-up display is
transmitted over the serial Manager port, as illustrated in Figure 7-1. Note that this display is only
visible from a serial connection, as the router will not accept a Telnet connection until initialization
is complete.
Figure 7-1. Start-up Display
Bootbase Version: V1.12 | 1/27/2000 18:31:01
RAM: Size = 4096 Kbytes
DRAM POST: Testing: 4096K OK
FLASH: intel 8M
RAS Version: V3.20(M.00) | 5/26/2000 19:43:28
Press any key to enter debug mode within 3 seconds.
..........................................
