Menu system
When the door to the heat pump is opened, the menu
system’s four main menus are shown in the display as
well as certain basic information.
,1'225 &/,0$7(
+($7 3803 ,1)2
+27 :$7(5
6(59,&(
,QGRRU WHPSHUDWXUH LI URRP VHQVRUV DUH LQVWDOOHG
+RW ZDWHU WHPS
7HPSRUDU\ OX[ LI
DFWLYDWHG
2XWGRRU WHPSHUDWXUH
(VWLPDWHG DPRXQW RI
KRW ZDWHU
,QIRUPDWLRQ DERXW
RSHUDWLRQ
Menu 1 - INDOOR CLIMATE
Setting and scheduling the indoor climate. See page 43.
Menu 2 - HOT WATER
Setting and scheduling hot water production. See page
50.
This menu only appears if a water heater is docked to
the heat pump.
Menu 3 - INFO
Display of temperature and other operating information
and access to the alarm log. See page 52.
Menu 4 - HEAT PUMP
Setting time, date, language, display, operating mode
etc. See page 53.
Menu 5 - SERVICE
Advanced settings. These settings are not available to the
end user. The menu is visible by pressing the Back button
for 7 seconds. See page 57.
Symbols in the display
The following symbols can appear in the display during
operation.
DescriptionSymbol
This symbol appears by the information
sign if there is information in menu 3.1 that
you should note.
These two symbols indicate whether the
compressor or addition is blocked in F1145.
These can, for example, be blocked depend-
ing on which operating mode is selected
in menu 4.2, if blocking is scheduled in
menu 4.9.5 or if an alarm has occurred that
blocks one of them.
Blocking the compressor.
Blocking additional heat.
This symbol appears if lux mode for the hot
water is activated.
This symbol indicates the actual speed of
the fan if the speed has changed from the
normal setting.
Accessory NIBE FLM required.
This symbol indicates whether "holiday
setting" is activated in menu 4.7.
NIBE™ F1145Chapter 7 | Control - Introduction40
