Menu 1 - INDOOR CLIMATE
Overview
1.1 - temperature1 - INDOOR CLIMATE
1.2 - ventilation *
1.3.1 - heating1.3 - scheduling
1.3.2 - cooling *
1.3.3 - ventilation *
1.9.1 - heating curve1.9 - advanced
1.9.2 - external adjustment
1.9.3 - min. flow line temp.
1.9.4 - room sensor settings
1.9.5 - cooling settings *
1.9.6 - fan return time *
1.9.7 - own curve
1.9.8 - point offset
* Accessories are needed.
Sub-menus
For the menu INDOOR CLIMATE there are several sub-
menus. Status information for the relevant menu can be
found on the display to the right of the menus.
temperature Setting the temperature for the climate
system. The status information shows the set values for
the climate system. Tab for cooling system is only dis-
played if accessory for cooling are present or if the heat
pump has the integrated cooling function.
ventilation Setting the fan speed. The status information
shows the selected setting. This menu is only displayed
if the exhaust air module is connected (accessory).
scheduling Scheduling heating, cooling and ventilation.
Status information "set" is displayed if you set a schedule
but it is not active now, "holiday setting" is displayed if
the vacation schedule is active at the same time as the
schedule (the vacation function is prioritised), "active"
displays if any part of the schedule is active, otherwise it
displays " off".
advanced Setting of heat curve, adjusting with external
contact, minimum value for supply temperature, room
sensor and cooling function.
Menu 1.1 - temperature
If the house has several climate systems, this is indicated
on the display by a thermometer for each system.
If the heat pump has an accessory for cooling or integ-
rated cooling function this is shown in the display with
an extra tab.
Set the temperature (with room sensors installed
and activated):
Setting range: 5 - 30 °C
Default value: 20
The value in the display appears as a temperature in °C
if the heating system is controlled by a room sensor.
To change the room temperature, use the control knob
to set the desired temperature in the display. Confirm
the new setting by pressing the OK button. The new
temperature is shown on the right-hand side of the
symbol in the display.
Setting the temperature (without room sensors
activated):
Setting range: -10 to +10
Default value: 0
The display shows the set values for heating (curve offset).
To increase or reduce the indoor temperature, increase
or reduce the value on the display.
Use the control knob to set a new value. Confirm the
new setting by pressing the OK button.
The number of steps the value has to be changed to
achieve a degree change of the indoor temperature de-
pends on the heating unit. One step for under floor
heating whilst radiators may require three.
Setting the desired value. The new value is shown on the
right-hand side of the symbol in the display.
43Chapter 8 | Control - MenusNIBE™ F1145
8 Control - Menus
