10
Basic Operations
Introduction
The m Button
Press m to display the menu for the selected mode. Use the rotary multi
selector to navigate the menus (c 9).
1
To display the anti-shake menu, enter anti-shake mode by pressing F
and then press m.
2
To display the one-touch portrait menu, enter one-touch portrait mode by
pressing A and then press m.
3
To display the print menu, connect the camera to a PictBridge-compatible
printer to display the print selection screen, and then press m.
4
To display the setup menu for shooting or playback mode, choose Z in
the shooting-mode or playback-mode selection menu and then press d.
• L Shooting menu (c 88) • i Playback menu (c 99)
• K High-sensitivity menu (c 88) • J Calendar menu (c 56)
• n Scene menu (c 34) • L List by date menu (c 56)
• F Anti-shake menu
1
(c 42) • w Print menu
3
(c 82)
• A One-touch portrait menu
2
(c 44) • Z Setup menu
4
(c 105)
• T Movie menu (c 63)
Shooting menu
Image mode
White balance
Continuous
BSS
ISO sensitivity
Exit
q
The selected option
Displayed when
there are one or
more menu items
to follow
Displayed when the
menu contains two
or more pages
Displayed when
there are more
previous menu
items
l
Shooting menu
Color options
AF area mode
Exit
Color options
Exit
Standard color
Black-and-white
Sepia
Cyanotype
Vivid color
Black-and-white
Sepia
Cyanotype
Vivid color
Press the rotary multi selec-
tor J or d to proceed to
the next set of options.
Press the rotary multi
selector J or d to
apply selection.
To Next Page
