nilan Compact P Software Instructions

Read data for ventilation and domestic hot water
I
t is possible to read off current data for Compact P ventilation and domestic hot water.
Information
Compact P all device data
↳
Software version Description: Shows the installed software version.
↳
Product Description: Shows the name of the product for which the software
has been set.
↳
Operating state Description: Shows the operating settings under which the unit is
working.
↳
Supply air fan Description: Shows the supply air fan's speed as %.
↳
Extract air fan Description: Shows the extract air fan's speed as %.
↳
Bypass damper Description: Shows whether the bypass damper is open or closed.
↳
Days outdoor air filter used Description: Shows number of days since last filter change.
↳
Days extract air filter used Description: Shows number of days since last filter change.
↳
After-heating element Description: Shows the capacity at which the after-heating element
is running (only if installed).
↳
Compressor state Description: Shows whether the compressor is running or not.
↳
Frost protection pre-heater Description: Shows the capacity at which the pre-heating element
is running (Polar version only).
↳
Current air humidity Description: Shows the current air humidity measured in the home.
↳
Average air humidity Description: Shows the average air humidity calculated over the
last 24 hours.
↳
CO2 level Description: Shows the current CO
2
level (only if installed).
↳
Fire alarm Description: Shows whether the fire alarm is activated or
deactivated.
↳
User selection 1 Description: Shows whether user selection program 1 is activated.
↳
User selection 2 Description: Shows whether user selection program 2 is activated.
↳
User selection 2 output Description: Shows whether user selection program 2 is active.
↳
Allow external cooling Description: Shows whether external cooling is activated.
↳
Allow external heating Description: Shows whether external heating is activated.
↳
Anti-legionella Description: Shows whether anti-legionella function is activated.
↳
Heat pump high pressure alarm Description: Shows whether there is a high pressure alarm in the
heat pump system.
↳
Sacrificial anode hot water tank Description: This must possibly be replaced if faulty.
↳
Electrical supplement hot water tank Description: Shows whether the supplementary electric heating is
active.
↳
De-icing heat exchanger Description: Shows whether the de-icing function for the heat
exchanger is active.
↳
De-icing heat pump Description: Shows whether the de-icing function for the heat pump
is active.
↳
Four-way valve Description: Shows whether the four-way valve is open or closed.
↳
Alarm Description: Shows whether there are active alarms.
↳
Blocking heating or cooling Description: Shows whether heating or cooling is blocked or not.
↳
Brine pressure switch BAH Description: Indicates whether the brine circuit is in working order.
Only with BAH solution.
↳
Heat valve Description: Shows whether the heat pump is heating the supply air
(Open).
↳
Hot water valve Description: Shows whether the heat pump is producing domestic
hot water (Open).
↳
Setpoint desired room temperature Description: Shows the setpoint for the desired room temperature.
↳
TExt room temperature Description: Shows the temperature in the control panel.
Compact P / Compact P Polar (English)
BY NILAN
41
