Nilfisk-Advance SC3000 Service Manual

Steering System 113Service Manual – SC3000
Steering System
Functional Description
The steering system connects the steering wheel to the driving wheel assembly.
The reduction gear pinion transmits the movement to the steering crown connected to the driving wheel as-
sembly. The driving wheel assembly is also equipped with the gear for “magic deck” system movement.
To reach the steering system, the machine front fairing must be removed.
Component Location
• Steering column
• Front fairing
2
1
Front fairing
Steering column
P100584
