Nokia G-2426G-A User Manual

Table 7-18 GRE Tunnel parameters (continued)
Field Description
Primary Remote End
Secondary Remote End (optional)
Enter an IP address or FQDN that is unique in the system.
If the primary remote endpoint is down or unreachable, the secondary remote endpoint
becomes active, if configured.
The secondary remote endpoint remains active until it becomes unreachable, in which
case the primary remote endpoint becomes active again. Revertive mode is not
supported.
If both endpoints are unreachable, the GRE tunnel is declared down.
Connected Remote End This field displays the current data traffic path for the GRE tunnel.
Connectivity check This feature is automatically selected by the system.
Traffic timeout to start pings Enter the traffic timeout in seconds (2 to 1024).
No. of retries before unreachable Enter the number of retries before the tunnel is declared down (0 to 100).
3
Click Save.
END OF STEPS
7.26 Configuring Upstream (US) Classifier
The US Classifier feature is used to create policies, classifiers, and classifier rules for upstream
traffic handling. This feature is available to admin users (super users) only.
A policy defines an action to be performed on a set of LAN or WAN packets. A policy can be created
at any time and then subsequently assigned to one or more classifiers.
A classifier is used to select key fields for which the classifier rules will be written. A classifier can be
created at any time and then subsequently assigned to one or more classifier rules.
A classifier rule is used to assign actions to a group of packets based on a set of parameters. A
classification rule must be created against a pre-defined classifier.
Up to 16 policies can be created, with up to 8 classifiers and 32 classifier rules.
1
Click Network→US Classifier from the left pane in the GPON Home Gateway page. The US
Classifier page displays.
Configure a G-2426G-A indoor ONT
Network configuration
Configuring Upstream (US) Classifier
7368 ISAM ONT
Draft Draft
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-XXXXX-AAAA-TCZZA
September 2020
112 Issue 1

Nokia G-2426G-A Specifications

General

Device Type	GPON ONT
Wi-Fi Frequency Bands	2.4 GHz, 5 GHz
Humidity	5% to 95% (non-condensing)
Wi-Fi Standards	IEEE 802.11 b/g/n
Power Supply	12V DC, 1.5A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C
Upstream Speed	1.25 Gbps
