Nokia G-2426G-A User Manual

6 Replace a G-2426G-A indoor ONT
6.1 Overview
6.1.1 Purpose
6.1.2 Contents
6.1 Overview 61
6.2 Purpose 61
6.3 General 61
6.4 Prerequisites 61
6.5 Recommended tools 61
6.6 Safety information 62
6.7 Procedure 62
6.2 Purpose
This chapter provides the steps to replace a G-2426G-A indoor ONT.
6.3 General
The steps listed in this chapter describe mounting and cabling for a G-2426G-A indoor ONT.
6.4 Prerequisites
You need the following items before beginning the installation:
• all required cables
6.5 Recommended tools
You need the following tools for replacing the ONT:
• #2 Phillips screwdriver
• 1/4 in. (6 mm) flat blade screwdriver
• wire strippers
• fiber optic splicing tools
• RJ-45 cable plug crimp tool
• voltmeter or multimeter
• optical power meter
Replace a G-2426G-A indoor ONT
Overview
7368 ISAM ONT
Draft Draft
September 2020
Issue 1 61
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-XXXXX-AAAA-TCZZA

Nokia G-2426G-A Specifications

General

Device Type	GPON ONT
Wi-Fi Frequency Bands	2.4 GHz, 5 GHz
Humidity	5% to 95% (non-condensing)
Wi-Fi Standards	IEEE 802.11 b/g/n
Power Supply	12V DC, 1.5A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C
Upstream Speed	1.25 Gbps
