Nokia G-2426G-A User Manual

Table 4-13 Package S ONTs PONONTTC, PONONTMCTC, PONONTTCHSI, PONONTTCCES,
PONONTTCFLOW, PONONTTCVOIP performance monitoring statistics
ONT PONONTTC, PONONTMCTC, PONONTTCHSI, PONONTTCCES, PONONTTCFLOW,
PONONTTCVOIP statistics
TXBLOCKS TXFRAGS RXBLOCKS RXFRAGS LOSTFRAGS BADGEMHDRS
G-2426G-A
1
✓ ✓ ✓ ✓ ✓ —
Notes:
1. A 5 second polling window limitation exists on the ONT, therefore the margin of error for each 15-min window
is 5 seconds
Table 4-14 Package S ONTs PONONTTC aggregate performance monitoring statistics
ONT PONONTTC (aggregate) statistics
TXBLOCKS TXFRAGS RXBLOCKS RXFRAGS LOSTFRAGS BADGEMHDRS
G-2426G-A
1
✓ ✓ ✓ ✓ ✓ —
Notes:
1. A 5 second polling window limitation exists on the ONT, therefore the margin of error for each 15-min window
is 5 seconds
4.10 G-2426G-A functional blocks
G-2426G-A indoor ONTs are single-residence ONTs that support Wireless (Wi-Fi) service. Wi-Fi
service on these ONTs is compliant with the IEEE 802.11 standard and enabled or disabled using a
WLAN button. In addition to the Wi-Fi service, these ONTs transmit Ethernet packets to four RJ-45
Ethernet ports and voice traffic to two RJ-11 POTS port. These ONTs also feature fiber optic, USB,
and power connectors.
Figure 4-3, “G-2426G-A ONT functional block” (p. 51) shows the functional blocks for G-2426G-A
indoor ONT.
G-2426G-A unit data sheet
G-2426G-A functional blocks
7368 ISAM ONT
Draft Draft
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-XXXXX-AAAA-TCZZA
September 2020
50 Issue 1

Nokia G-2426G-A Specifications

General

Device Type	GPON ONT
Wi-Fi Frequency Bands	2.4 GHz, 5 GHz
Humidity	5% to 95% (non-condensing)
Wi-Fi Standards	IEEE 802.11 b/g/n
Power Supply	12V DC, 1.5A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C
Upstream Speed	1.25 Gbps
