Oki ML3410 User Manual

Testing Your Printer
Testing Your Printer
Your Pacemark printer has two built-in tests to make sure your printer is working properly. Run these
after you've set up your printer and any time you want to verify that it•s running. The top of each print test
contains information on your printer model. Be sure to have a copy of the printout handy if you call for
service.
Important
Use only continuous forms paper to run these tests.
Print Sample Test
Turn the printer on while holding down the LINE FEED button. The test prints a two-page sample of your
Pacemark•s printing styles. Press the SELECT button or turn off the printer to stop the test.
Rolling ASCII Test
Turn the printer on while holding down the FORM FEED button. This test prints the character set in a
rolling pattern using the default type style. Press the SELECT button or turn off the printer to stop the
test.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
