Setting Top of Form
Setting Top of Form
The top of form is the place on the page where printing starts. When the printer advances to the
next page, it stops at the top of form.
Your Pacemark printer stores the top of form position independently for the three standard types of
paper feeding top, rear, and bottom.
The method of setting top of form is the same for all types of paper:
1. Feed a page into the printer by pressing the FORM FEED button.
2. Hold down the TOP OF FORM button while you adjust the page up or down using the MICRO
FEED buttons. The red line on the plastic ribbon shield marks the base of the printing line•use
this as a guide.
3. When you release the TOP OF FORM button, the position will be registered in the printers
memory until you change it.
Note
If you want to reset the top of form to its original settings, turn off the printer, then hold down the
SELECT and TOP OF FORM buttons while turning it on again. Keep in mind, however, that this
will also cancel any changes you've made to the menu.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
