Oki ML3410 User Manual

Print Quality
Print Quality
This allows you to select the level of printing quality suitable to your needs.
High Speed Draft (HSD) is the fastest printing mode (550 characters per second). It's suited for situations
where speed is more important than appearance, such as editing or proofing a document before final
printing.
Utility printing is for everyday use, such as memos and internal documents.
When you want correspondence and documents to look their best, use one of the two Near Letter Quality
typefaces: Courier and Gothic.
Press the PRINT QUALITY button until the light next to your choice is lit.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
