Front Turn Signal
The turn signal bulb is on the inboard edge of the
headlamp assembly.
To
replace a bulb, do the following:
1.
2.
3.
4.
Remove the headlamp assembly if you need more
hand clearance.
Reach in and press the locking tab while twisting the
bulb assembly one-quarter of a turn
counterclockwise.
Replace the bulb and reverse Step
2
to reassemble.
If
you
removed the headlamp assembly, reassemble
it by aligning the pin and tightening the two bolts to
secure
it.
Headlamp
Aiming
Your vehicle has the composite headlamp system. These
headlamps have horizontal and vertical aim indicators.
The aim has been pre-set at the factory and should need
no further adjustment.
If
your vehicle is damaged
in
an
accident and the
headlamp aim seems
to
be affected, see your Aurora
retailer. Headlamps on damaged vehicles may require
recalibration
of
the horizontal aim by your Aurora retailer.
To
check
the
aim, the vehicle should be properly
prepared as
follows:
e
0
e
The vehicle must have all four tires on a perfectly
level surface.
The vehicle should not have
any
snow, ice
or
mud
attached to it.
There should not be any cargo or loading of the
vehicle, except it should have a full tank
of
gas and
one person or
160
lbs.
(75
kg) on the driver’s seat.
Tires should be properly inflated.
I
NOTICE:
To
make sure your headlamps are aimed
properly, read all the instructions before
beginning. Failure to
follow
these instructions
could cause damage to headlamp parts.
State inspection stations will allow a vertical reading of
plus
0.76
degrees or minus
0.76
degrees from the center
of
the bubble.
It
is recommended that the upper limit not exceed plus
0.4
degrees from the center of the bubble. Other drivers
may flash their high beams at
you
if your adjustment is
much above plus
0.4
degrees.
6-37
