Olympus CX43 User Manual

16
4-5 Tube portion
1
Adjusting the interpupillary distance
The interpupillary distance adjustment is to adjust the distance between
two eyepieces according to the distance between your eyes. This makes
it possible to observe a single image and to reduce eye strain during
observation.
Keep the right and left eyepieces horizontally. While looking through
the eyepieces, move the binocular portion either in
a
or
b
direction
until the right and left fields of view coincide completely. The value
shown by the indicator (
·)
c
on the eyepiece sleeve represents your
interpupillary distance.
Be sure to make the interpupillary distance same between
right and left.
Note your interpupillary distance so that it can be easily adjusted
next time.
1
NOTE
TIP
When wearing eyeglasses
Use the eye shades in the normal, folded-down position.
When not wearing eyeglasses
Extend the folded eye shades in the arrow direction. Since the eye shades
prevent the unnecessary light from entering between eyepieces and eyes,
you can observe the specimen comfortably.
2
Using the eye shades
a
b
c

Olympus CX43 Specifications

General

Category	Microscope
Type	Biological Microscope
Illumination	LED
Focus	Coaxial coarse and fine focus knobs
Optical System	UIS2 optical system
Power Supply	AC 100-240V, 50/60 Hz
Observation Method	Brightfield
Eyepiece	10x
Objective Lenses	4x, 10x, 40x, 100x
Stage	Mechanical stage
Condenser	Abbe condenser (N.A. 1.25)
Nosepiece	Revolving nosepiece with 4 positions
