5 Various observation methods
5-1 Transmitted phase contrast observation method
This section describes the procedures of observation methods other than brightfield/darkfield observations. For brightfield and
darkfield observations, see "3 Transmitted brightfield/darkfield observation methods".
For the phase contrast observation, the objective for phase contrast and the centering telescope (CT-5) are necessary.
If the analyzer for simple polarization and the polarizer are engaged in the light path, remove them from the light path.
5 Revolving nosepiece 14
2 Condenser turret 19
Engage the objective for phase contrast in the light path.
Center the ring slit.
6 Coarse/fine focusing knobs 14
Observation
b Various filters 9
7 Brightness adjustment knob 9
Adjust the brightness.
Place the necessary filter.
Select either Ph1, Ph2 or Ph3 (phase contrast observation).
a Ring slit centering knob 25
(Operation portion) (Page)
2 Condenser turret 19
5 Revolving nosepiece 14
1 Main switch 9
3 Specimen holder 10
4 X-axis/Y-axis knobs 11
6 Coarse/fine focusing knobs 14
8 Binocular portion 16
9 Diopter adjustment ring 17
7 Brightness adjustment knob 9
Place the specimen on the stage.
Engage the 10X objective in the light path.
Bring the specimen into focus and adjust the brightness.
Set the main switch to (ON).
Select BF (brightfield observation).
Adjust the interpupillary
distance.
Adjust the diopter.
Bring the specimen into focus.
To Next Page
