16
Chapter 3 Cleaning, Disinfection and Sterilization Procedures
EVIS EXERA GIF/CF/PCF TYPE 160 Series REPROCESSING MANUAL
Reprocessing equipment parts and functions
For inspection of other equipment than that mentioned below, refer to the
instruction manual for the equipment being used.
Water-resistant cap (MH-553)
The water-resistant cap is attached to the electrical connector on the endoscope
to protect the connector from water penetration during reprocessing. For leakage
testing, the venting connector on the water-resistant cap must be connected to
the leakage tester (see Figure 3.2).
Figure 3.2
Water-resistant cap (MAJ-583 for CF-Q160ZL/I only)
The water-resistant cap (MAJ-583) is attached to the zoom connector on the
endoscope to protect the connector from water penetration during reprocessing.
The water-resistant cap is connected to the endoscope by a chain (see Figure
3.3).
Figure 3.3
