Chapter 3 Cleaning, Disinfection and Sterilization Procedures
19
EVIS EXERA GIF/CF/PCF TYPE 160 Series REPROCESSING MANUAL
Channel cleaning brush (BW-17K, BW-20T)
The channel cleaning brush is used to brush the inside of the instrument/suction
channels and the holes in the air/water and suction valves (see Figure 3.8).
Figure 3.8
Channel-opening cleaning brush (MH-507)
The channel-opening cleaning brush is used to brush the external surface of the
distal end of the endoscope, the suction cylinder and the instrument channel port
(see Figure 3.9).
Figure 3.9
