Olympus XZ-10 User Manual

5 EN
Preparations for shooting
1
Inserting and removing the battery and card
1
Follow Steps 1 and 2 to open the
battery/card compartment cover.
• Turn off the camera before opening the battery/
card compartment cover.
2
1
Battery/card compartment lock
Battery/card compartment cover
2
Insert the battery while sliding the battery
lock knob in the direction of the arrow.
• Insert the battery as illustrated with the
l
mark
toward the battery lock knob.
Damage to the battery exterior (scratches, etc.)
may produce heat or an explosion.
• Slide the battery lock knob in the direction of the
arrow to unlock, and then remove the battery.
Battery lock knob
3
Insert the card straight until it clicks into
place.
• Always use SD/SDHC/SDXC cards, Eye-Fi card
or FlashAir (wireless LAN mounted) card with
this camera. Do not insert other types of memory
cards. g “Using the card” (P. 72)
• Do not touch the metallic parts of the card
directly.
Write-protect switch
To remove the card
Press the card in until it clicks and comes out
slightly, then remove the card.
4
Follow Steps 1 and 2 to close battery/
card compartment cover.
• When using the camera, be sure to close the
battery/card compartment cover.
2
1

Olympus XZ-10 Specifications

General

Sensor Type	CMOS
Sensor Size	1/2.3 inch
ISO Sensitivity	100 - 6400
Lens	Olympus i.Zuiko Digital
Storage Types	SD/SDHC/SDXC
Battery	Li-ion Battery
Type	Compact
Digital Zoom	4x
Continuous Shooting	5 fps
Battery Model	LI-50B
Image Processor	TruePic VI
LCD Screen Type	TFT LCD
Effective Pixels	12.0 megapixels
Max Aperture	f/1.8-2.7
LCD Screen	3.0-inch
Video Resolution	1920 x 1080 (Full HD)
Weight	221 g (with battery and memory card)
Image Stabilization	Sensor-shift
Shutter Speed	1/2000
Dimensions	102.4 x 61.1 x 34.3 mm
