2.2.2 ACCESSORIES
The Builder has foreseen and designed a wide range of accessories integrating the machine.
The available accessories are:
- adjustable motorized pre-stretch;
- ramp to access the table with transpallets;
- clamps to fix the ramp to the ground;
- pit frame;
- machine feet allowing the use of pallet stacker;
- disconnector;
- clip to tie the film to the turntable;
- potentiometer to control the film tension;
- multi-turn potentiometer to control the film tension;
- stopped by 90°;
- photocell for black load;
- automatic cutting of the film;
- external pushbutton to return to the program memorized;
- Start or Reset or Esc or Stop by external pushbutton;
- light signal on the main column;
- low and/or high fixed roping system;
- limit switch on pre-stretch carriage door.
Ac
cessories, especially if combined, are sufficient to satisfy main needs, improving the machine’s
performance and simplifying its use.
The description and the operating instructions of additional accessories are enclosed to the main
operating and maintenance “base” machine manual.
2.3 TECHNICAL DATA
The following are the data and the technical characteristics for a correct installation.
SUPPLY VOLTAGE (V) 230
ABSORBED POWER (kW) REFER TO DATA ON PLATE
MASS (kg) REFER TO DATA ON PLATE
DIMENSIONS (mm) REFER TO PARAGRAPH 2.5
MAXIMUM LOAD WEIGHT (kg) REFER TO DATA ON PLATE
ROTATION SPEED (RPM) 12
ROTATION WISE CLOCKWISE
(*)
(*) If the carriage rotation group is present, the direction of rotation of the table must be anti-clockwise.
CEC BASE IGM REV13 18
