7 Precautions for Use of Parameters for DriveProgramming
7 - 2
DriveProgramming User’s Manual (I622-E1)
7-1 Inverter Parameters Affected by
Setting Order
In some cases, the setting range of the parameters are restricted by the setting data of other parameters.
The following are the representative examples.
For details, refer to the High-function General-purpose Inverter 3G3RX2 Series User's Manual (I620).
Parameter
No.
Description Data
Hb104 Async.Motor Base frequency setting, 1st-
motor
10.00 to Maximum Frequency [Hb105](Hz)
Hb105 Async.Motor Maximum frequency setting, 1st-
motor
Base Frequency [Hb104] to 590.00 (Hz)
Hd104 Sync.Base frequency setting, 1st-motor 10.00 to Maximum Frequency [Hd105](Hz)
Hd105 Sync.Maximum frequency setting, 1st-motor Base Frequency [Hd104] to 590.00 (Hz)
Hb204 Async.Motor Base frequency setting, 2nd-
motor
10.00 to Maximum Frequency [Hb205](Hz)
Hb205 Async.Motor Maximum frequency setting,
2nd-motor
Base Frequency [Hb204] to 590.00 (Hz)
Hd204 Sync.Base frequency setting, 2nd-motor 10.00 to Maximum Frequency [Hd205](Hz)
Hd205 Sync.Maximum frequency setting, 2nd-motor Base Frequency [Hd204] to 590.00 (Hz)
AA104 Sub speed setting, 1st-motor 0.00/Minimum Frequency [Hb130][Hd130] to Maxi-
mum Frequency [Hb105][Hd105](Hz)
AA204 Sub speed setting, 2nd-motor 0.00/Minimum Frequency [Hb230][Hd230] to Maxi-
mum Frequency [Hb205][Hd205](Hz)
Ab110 Multispeed-0 setting, 1st-motor 0.00/Minimum Frequency [Hb130][Hd130] to Maxi-
mum Frequency [Hb105][Hd105](Hz)
Ab210 Multispeed-0 setting, 2nd-motor 0.00/Minimum Frequency [Hb230][Hd230] to Maxi-
mum Frequency [Hb205][Hd205](Hz)
Ab-11 to
Ab-25
Multispeed-1 setting to 15 setting 0.00/Minimum Frequency [Hb130][Hd130] to Maxi-
mum Frequency [Hb105][Hd105](Hz)
bA-60 Dynamic brake usage rate 0.0 to 10.0 × (Dynamic brake usage rate resistance
[bA-63]/Minimum resistance)
2
(%)
bA102 Upper Frequency limit, 1st-motor Upper Frequency limit, 1st-motor [bA102] ≤
Async.Motor Maximum frequency setting, 1st-motor
[Hb105]
Upper Frequency limit, 1st-motor [bA102] ≤
Sync.Maximum frequency setting,
1st-motor[Hd105]
bA103 Lower Frequency limit, 1st-motor Lower Frequency limit, 1st-motor [bA103] ≤
Async.Motor Maximum frequency setting, 1st-motor
[Hb105]
Lower Frequency limit, 1st-motor [bA103] ≤
Sync.Maximum frequency setting,
1st-motor[Hd105]
bA202 Upper frequency limit, 2nd motor Upper frequency limit, 2nd motor [bA202] ≤
Async.Motor Maximum frequency setting, 2nd-
motor [Hb205]
Upper frequency limit, 2nd motor [bA202] ≤
Sync.Maximum frequency setting, 2nd-motor
[Hd205]
