5 DriveProgramming User Variables
5 - 6
DriveProgramming User’s Manual (I622-E1)
• The input terminal variable (word access) Xw is a function to use the input terminal variables X(00) to
X(10) as a word-size variable. This variable is read-only.
• The input terminal variables X(00) to X(10) are set to the bit 0 to 10. For the from bit 11 and unused
input terminal variables, zero is read out.
Precautions for Correct Use
• When the DriveProgramming program is stopped, the status of the input terminal variables is
not retained but updated according to the status of actual input terminals.
• For Input terminal 1 to 9, A and B, when MI1 to MI11 (General-purpose input 1 to 11) is
selected, Input terminal [21 to 31] active state (CA-21 to CA-31) is set to NO or NC.
You can use the inverter's output terminals as the output terminals Y(00) to Y(06) for the DriveProgram-
ming function by setting the output terminals to the general-purpose outputs MO1 to MO7.
When Yw variables are used, the output terminal variables Y(00) to Y(06) can be used as word access
data.
• You can control the status of the output terminals 11 to 15 and the relay output terminals (16, AL) as
bit-size variables.
• By setting the Output terminal 11 to 15 Selection (CC-01 to CC-05) or the Relay Output (16, AL)
Function Selection (CC-06, CC-07) to 69 to 75 (MO1 to MO7: General-purpose output), you can con-
trol the output terminals 11 to 15 or the relay output terminals (16, AL) as the output terminal vari-
ables Y(00) to Y(06) of the DriveProgramming. Numbers are given to the input terminal variables
Y(00) to Y(06) according to the numerical order of the set general-purpose inputs MO1 to MO7, not
the terminal numbers 11 to 15, 16 and AL.
Function
variable
Description Data range
Default
data
Unit Data size R/W
Xw Input terminal variable
(word access)
0 to 65,535 0 − Unsigned
1 word
R
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Function X
(15)
X
(14)
X
(13)
X
(12)
X
(11)
X
(10)
X
(9)
X
(8)
X
(7)
X
(6)
X
(5)
X
(4)
X
(3)
X
(2)
X
(1)
X
(0)
Output Terminal Variables Y(00) to Y(06)
Function
variable
Description Data range
Default
data
Unit Data size R/W
Y(00) to Y(06)
Output terminal variable
(bit access)
0: OFF
1: ON
0 − bit R
