5 DriveProgramming User Variables
5 - 22
DriveProgramming User’s Manual (I622-E1)
CON Contactor control R CC-01 to CC-07 = 39
ZS 0 Hz detection signal R CC-01 to CC-07 = 40
DSE Excessive speed deviation R CC-01 to CC-07 = 41
PDD Excessive positional deviation R CC-01 to CC-07 = 42
POK Positioning completed R CC-01 to CC-07 = 43
PCMP Pulse count compare-match output R CC-01 to CC-07 = 44
OD PID excessive deviation R CC-01 to CC-07 = 45
FBV PID feedback comparison R CC-01 to CC-07 = 46
OD2 PID2 excessive deviation R CC-01 to CC-07 = 47
FBV2 PID2 feedback comparison R CC-01 to CC-07 = 48
NDc Communication disconnection R CC-01 to CC-07 = 49
Ai1Dc to Ai3Dc Analog disconnection Ai1 to 3 R CC-01 to CC-07 = 50 to 52
WCAi1 to WCAi3 Window comparator Ai1 to 3 R CC-01 to CC-07 = 56 to 58
LOG1 to LOG7 Result of logical operation 1 to 7 R CC-01 to CC-07 = 62 to 68
MO1 to MO7 General purpose output 1 to 7 R CC-01 to CC-07 = 69 to 75
EMFC Forced operation in process signal R CC-01 to CC-07 = 76
EMBP During-bypass-mode signal R CC-01 to CC-07 = 77
LBK Operation panel battery insufficient R CC-01 to CC-07 = 80
OVS Excessive voltage of accepted power R CC-01 to CC-07 = 81
AC0 to AC3 Alarm code bit 0 to 3 R CC-01 to CC-07 = 84 to 87
OD3 PID3 excessive deviation R CC-01 to CC-07 = 89
FBV3 PID3 feedback comparison R CC-01 to CC-07 = 90
OD4 PID4 excessive deviation R CC-01 to CC-07 = 91
FBV4 PID4 feedback comparison R CC-01 to CC-07 = 92
SSE PID soft start abnormality R CC-01 to CC-07 = 93
Function variable Description R/W Reference
