6 Parameters
6 - 32
E5@C Digital Temperature Controllers User’s Manual (H174)
wt-b
Wait Band
The Program Pattern parameter must not be set to
OFF.
• This parameter sets the stable band within which the soak time is measured for the
simple program function.
 Related Parameters
Program Start (Operation Level): Page 6-12
Soak Time Remain (Operation Level): Page 6-13
Soak Time (Adjustment Level): Page 6-31
Program Pattern (Initial Setting Level): Page 6-47
Soak Time Unit (Advanced Function Setting Level): Page 6-84
mV-s
MV at Stop
The control must be set to 2-PID control or a
Position-proportional Model must be used.
The MV at Stop and Error Addition parameter must
be ON.
• This parameter sets the MV to use when the RUN/STOP status changes from RUN to
STOP.
 Related Parameters
RUN/STOP (Operation Level): Page 6-13
MV at Stop and Error Addition (Advanced Function Setting Level): Page 6-74
Close/Floating (Initial Setting Level): Page 6-59
Direct Setting of Position Proportional MV (Advanced Function Setting Level): Page 6-88
000
Function
Setting
Setting range Unit Unit
Temperature input OFF or 0.1 to 999.9 °C or °Foff
Analog input OFF or 0.01 to 99.99 %FS
See
See
000
Function
Setting
Control method Setting range Unit Default
Standard control
Close position-proportional control with the Direct Setting
of Position-proportional MV parameter set to ON
−5.0 to 105.0 % 0.0
Heating/cooling control −105.0 to 105.0
Floating position-proportional control or the Direct Setting
of Position-proportional MV parameter set to OFF
CLOS, HOLD, or
OPEN
None HOLD
See
See
