Omron E5CC User Manual

6 - 67
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-8 Advanced Function Setting Level
6
st-b
ST Stable Range
Temperature input, standard control, 2-PID control
must be set.
The ST parameter must be set to ON.
• The setting of this parameter determines when ST operates.
This parameter cannot be used when ST is set to OFF.
 Related Parameters
Input Type (Initial Setting Level): Page 6-43
PID ON/OFF (Initial Setting Level): Page 6-45
ST (Initial Setting Level): Page 6-46
alfa
α
2-PID control must be set.
The ST parameter must be set to OFF.
• Normally, use the default for this parameter.
• This parameter sets the 2-PID control a constant.
 Related Parameters
PID ON/OFF (Initial Setting Level): Page 6-45
ST (Initial Setting Level): Page 6-46
tidu
Integral/Derivative Time Unit Control must be set to 2-PID control.
This parameter sets the time unit for the Integral Time, Integral Time (Cooling), Derivative
Time, and Derivative Time (Cooling) parameters.
Note: The Integral/Derivative Time Unit parameter changes to 0.1 when the RT (robust tuning)
parameter is changed from OFF to ON.
 Related Parameters
Integral Time and Derivative Time (Adjustment Level): Page 6-28
Derivative Time (Cooling) and Integral Time (Cooling) (Adjustment Level): Page 6-29
Function
Setting
Setting range Unit Default
0.1 to 999.9 °C or °F 15.0
See
See
Function
Setting
Setting range Default
0.00 to 1.00 0.65
See
See
Function
Setting
Setting range Unit Default
1 to 0.1 Seconds 1
See
See

Omron E5CC Specifications

General

Number of Display Digits	4 digits
Number of Control Outputs	1
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage, Analog current
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Display Type	LCD
Size	48 x 48 mm
Mounting Method	Panel mount
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
Protection Rating	IP66
