4 Installation and Wiring
4-38
NJ-series CPU Unit Hardware User’s Manual (W500)
OMRON Connecting Cable can be used to connect Basic I/O Units with Connectors to OMRON Con-
nector-Terminal Block Conversion Units or to OMRON I/O Relay Terminals. For details, refer to A-2-4
Connecting Connector-Terminal Block Conversion Units and I/O Relay Terminals.
 Connection Examples
4-4-5 Connecting to Connector-Terminal Block Conversion Units or I/O
Relay Terminals
Connector-Terminal Block Conversion Unit I/O Relay Terminals
Connector-Terminal Block
Conversion Unit
40 or 60 terminals
Basic I/O Unit
Connecting Cable
I/O Relay Terminal
Connecting Cable
Basic I/O Unit
