A-1 Datasheets
A
A-1-2 Incremental Encoder Input Units
NX-EC0122
Unit name Incremental Encoder Input Units Model NX-EC0122
Number of channels
1 channel
Type of external con-
nections
Screwless clamping terminal block
(16 terminals)
I/O refreshing
method
*1
Free-Run refreshing, synchronous I/O refreshing, or task period prioritized refreshing
Indicators
Refer to NX-EC0112 and
NX-EC0122 on page 6-9.
Input signals
Counter: Phases A, B, and Z
External Inputs: 3
Input form Voltage input (24 V)
Counting unit Pulses
Pulse input method
Phase differential pulse (multiplication x2/4), pulse + direction inputs, or up and down pulse
inputs
Counter range −2,147,483,648 to 2,147,483,647 pulses
Counter functions
Counter type Ring counter or linear counter
Counter controls Gate control, counter reset, and counter preset
Latch function Two external input latches and one internal latch
Measurements Pulse rate measurement and pulse period measurement
Voltage input specifications
Input voltage
20.4 to 28.8 VDC (24 VDC
+20%/−15%)
ON voltage
19.6 VDC min./3 mA min.
Input current 4.2 mA typical (24 VDC) OFF voltage 4.0 VDC max./1 mA max.
Maximum response
frequency
Phases A and B: Single-phase 500 kHz (phase differential pulse input x4: 125 kHz), Phase Z:
125 kHz
Internal I/O com-
mon processing
PNP
External input specifications
Input voltage
20.4 to 28.8 VDC (24 VDC
+20%, −15%)
ON voltage/ON cur-
rent
15 VDC min./3 mA min.
Input current
4.6 mA typical (24 VDC)
OFF voltage/OFF
current
4.0 VDC max./1 mA max.
ON/OFF response
time
1 μs max./2 μs max.
Internal I/O com-
mon processing
PNP
Dimensions 12 × 100 × 71 mm (W×H×D) Isolation method Photocoupler isolation
Insulation resistance
20 MΩ min. between isolated cir-
cuits (at 100 VDC) Dielectric strength
510 VAC between isolated circuits
for 1 minute with leakage current of
5 mA max.
I/O power supply
method
Supplied from the NX bus.
20.4 to 28.8 VDC (24 VDC
+20%, −15%)
Current capacity of
I/O power supply ter-
minals
IOV: 0.3 A max. per terminal for
encoder supply section and 0.1 A
max. per terminal for other sections
IOG: 0.3 A max. per terminal for
encoder supply section and 0.1 A
max. per terminal for other sections
NX Unit power con-
sumption
0.95 W max.
Current consump-
tion from I/O power
supply
None
Weight 70 g max.

Omron NX-EC0122 Specifications

General

Brand	Omron
Model	NX-EC0122
Category	Controller
Language	English
