Omron SMARTSTEP R7D-AP Series User Manual

Chapter 2
2-8
Standard Models and Specifications
■ Single-phase/Three-phase 200 V AC: R7D-AP08H (750 W)
● Wall Mounting
● Front Panel Mounting (Using Mounting Brackets)
External dimensions
Mounted dimensions
5 dia.
90
160
(75) 180
17
Two, M4
149.5±0.5
160
5.5
(5)
90
27
149.5 5.5(5)
External dimensions Mounted dimensions
5 dia.
7.5(7.5)
5
42
24.5
2
180 195
180±0.5
195
7.5(7.5)
Two, M4
10
22.5
43.5
52 12.5
(168) 66
