Omron V7 Quick Manual

EN-4
30 mm*
(1,18 in.)
or more
30 mm*
(1,18 in.)
or more
100 mm (3,94 in.)
or more
100 mm (3,94 in.)
or more
AIR
AIR
*: Inverter size 5.5 / 7.5 kW min. space
50 mm
EMC Installation
CIMR-V7AZ40P2 to 47P5 CIMR-V7AZB0P1 to B4P0
CIMR-V7AZ20P1 to 27P5
Mounting Dimensions
Shield Cable
Ground
Bonds
(remove
any paint)
Shield
Cable
Metal
Mounting
Plate
L1 L2 L3 PE
Ground
Bonds
(remove
any paint)
Filter
Max. 20 m
Motor Cable
Control Panel
Shield Cable
Ground
Bonds
(remove
any paint)
Shield
Cable
Ground Bonds
(remove any paint)
Metal
Mounting
Plate
PE
N
Ground
Bonds
(remove
any paint)
Filter
Max. 20 m
Motor Cable
Control Panel
I43-EN-01+V7+Quick_Guide.book Seite 4 Dienstag, 25. April 2006 8:56 08
