EN-12
Quick Parameter List
Parameter
No.
Description Range Default
n001
Parameter access:
1: Limited parameter access
4: Full parameter access
12: Factory parameter initialise
0 to 13 1
n002
Control mode selection:
0: V/F control mode
1: Vector control mode
0.1 0
n003
Run Command
0: Digital operator RUN, STOP/RESET
1: Control circuit terminal run/stop
2: Communications (MEMOBUS)
3: Communications (option)
0 to 3 0
n004
Frequency reference selection:
0: Digital operator (potentiometer)
1: Frequency reference 1 (n024)
2: Control circuit terminal (0 to 10V)
3: Control circuit terminal (4 to 20mA)
4: Control circuit terminal (0 to 20mA)
5: Control circuit terminal (Pulstrain reference)
6: Communications (MEMOBUS)
7: Digital operator circuit (0 to 10V)
8: Digital operator circuit (4 to 20 mA)
9: Communication (option)
0 to 9 1
n011
Maximum output frequency 50 to 400Hz 50Hz
n012
Maximum output voltage 0.1 to 255V (200V class)
0.1 to 510V (400V class)
200 (200V class)
400 (400V class)
n019
Acceleration time 1 0.0 to 6000sec 10 sec
n020
Deceleration time 0.0 to 6000sec 10sec
n024
Frequency reference 1 0.0 to 400Hz 6Hz
n025-n031
Frequency reference 2-8 0.0 to 400Hz 0Hz
n036
Motor rated current Depending on model 0 to 150% of inverter rated
output current
n050-n056
Multi-function input (S1-S7) 0 to 35 -
n057
Multi-function output (MA-MB-MC) 0 to 21 1
n066
Multi-function analog output (AM-AC):
0: Output frequency (10V/Max, freq.)
1: Output current (10V/Inverter rated current)
0 to 6 0
n080
Carrier frequency 1 to 4 (2.5 - 10kHz)
7 to 9
(Proportional to output freq.)
Depending on model
I43-EN-01+V7+Quick_Guide.book Seite 12 Dienstag, 25. April 2006 8:56 08
