16
There are 60 programs as 1 Manual Program, 49 Preset Programs, 1 Body Fat Program, 4 Heart
Rate Control Programs, 4 User Setting Programs, 1 WATT Control Program.
C. Program Graph:
Each graph shown is the profile of the loading in each interval (column). With the value of TIME
counting up, each interval is 3 minutes that all the columns make up 30 minutes. With the value of
TIME counting down, each interval is the value of setup TIME divided by 10. For example, if the
time value is setup to 40 minutes, each interval will be 40 minutes divided by 10 intervals (40/10=4).
Then, each interval will be 4 minutes. The following graphs are all the profiles in the monitor.
PROGRAM 1 (MANUAL)：
PROGRAM 2 ~ 50：
P2 P3 P4
P5 P6 P7
P8 P9 P10
P11 P12 P13
To Next Page
