Part List
Part No Description Qty Part No Description Qty
A01 Welded,main frame 1 C01 Main Cover- Right 1
A02 Welded,Upright Support 1 C02 Main Cover- Left 1
A03 Welded,Dual Action Tube Left 1 C03 Disc Cover 2
A04 Welded,Dual Action Tube Right 1 C04 End Cap for Stabilizer Bar 2
A05 Welded,Foot Pedal Tube Left 1 C05 Height Adjuster 6
A06 Welded,Foot Pedal Tube Right 1 C06 Transportation Wheel 2
A07 Welded,Foot Tube Left 1 C07 Upright Joint Cover Left 1
A08 Welded,Foot Tube Right 1 C08 Upright Joint C
over Right 1
A09 Welded,Tension Wheel Arm 1 C09 End Cap for Foot Pedal Tube 2
A10 Welded,Shaft Pulley 1 C10 Belt 1
A11 Welded,Crank Assembly 2 C11 Nut Cap 2
A12 Welded,Guide Rails Tube 1 C12 Foot Pedal 2
A13 Dual Action Handlebar Left 1 C13 Foam Grip 2
A14 Dual Action Handlebar Right 1 C14 Plug 2
A15 Welded,Hand Bar 1 C15 Foam Grip 2
B01 1/4”Hex Bolt 2 C16 Square End Cap 20x40 2
B02 1/4”Washer 4 C17 Pivot Cover L 2
B03 1/4”Lock Nut 2 C18 Pivot Cover R 2
B
04 3/8"Nut 2 C19 Pulley 1
B05 M6 Screw 2 C20 Roller 4
B06 C Clip 1 C21 Pivot Cap for Crank Link Tube 2
B07 Wave Washer 2 C22 Washer 4
B08 M20 Washer 1 C23 Spacer 2
B09 38 Washer 1 C24 Bearing Bushing 10
B10 M8 Hex Head Screw 1 C25 Bearing Housing 10
B11 M10 Allen Key Screw 1 C26 Bushing 6
B12 M3 Sheet Metal Screw 2 C27 Water Bottle Holder 1
B13 M8 Allen Key Screw 20 C28 D Shape End Cap for Stabilizer Bar L 2
B14 M8 Hex Head Screw 4 C29 D Shape End Cap for Stabi
lizer Bar R 2
B15 M5 Allen Key Screw 2 C30 Pivot Cap L 2
B16 M8 Screw 2 C31 Pivot Cap R 2
B17 Screws for Computer 4 C32 Wheel Cap L 2
B18 Tension Adjustment Screw 2 C33 Wheel Cap R 2
B19 M6 Lock Nut 2 C34 Cushion Pad 2
B20 M3 Bolt 2 C35 Upright Tube Spacer 2
B21 M5 Sheet Metal Screw 55 C36 Small Crank Decorated Cover 2
B22 Zinc Plate 2 D01 Hand Pulse Sensor 1Set
B23 M6 Allen Key Screw 8 D02 Computer 1
B24 M8 Allen Key Screw 2 D03 Magnetic Flywheel 1
B25 M8 B
lack Nut 1 D04 Cable 1
B26 M10 Lock Nut 3 D05 Cable 1
B27 C Clip 1 D06 Motor with cable 1
B28 M8 Carriage Bolt 4 D07 Sensor Cable 1
B29 M8 Lock Nut 6 D08 AC Adaptor 1
B30 M8 Curve Washer 24 D09 AC Plug Cable 1
B31 Shaft for Dual Action Arm Pivot 2 D10 Hand Pulse Cacle 1Set
B32 M8 Hex Head Screw 10 D11 Motor Tension Cable 1
B33 5/16" Washer 8 D12 Left Quick Key 1
B34 M10 Hex Head Screw 2 D13 Right Quick Key 1
B35 M8 Allen Key Screw 4 D14 Hand Pulse Sensor 2Set
B
36 5/16" Washer 4 D15 Handpulse Cable 2
B37 3/16" Sheet Metal Screw 1 D17 Right Quick Key Cable 2
B38 M3 Sheet Metal Screw 2 D18 Left Quick Key Cable 2
B39 M4 Sheet Metal Screw 6 E01 Bearing 6004 2
B40 M8 Screw 2 E02 Bearing 6003 10
B41 Bushing Spacer 10 E03 Bearing 6902 8
B42 M5 Sheet Metal Screw 2 E04 Bearing 6203 2
B43 Screw 4 F01 Aluminum Guide Rails 4
To Next Page
