5 Installation
−12−
5 Installation
This chapter explains the installation location and installation methods of the motor
and driver, as well as how to install a load. Read the applicable sections carefully to
install each item correctly.
Geared type
Combination type parallel shaft gearhead
P.13, 19
Combination type hollow shaft flat gearhead P.15, 22
Round shaft type P.18, 19
Pinion shaft type
Parallel shaft gearhead: P.13, 19
Hollow shaft flat gearhead: P.15, 22
5.1 Installation location
The motor and driver are designed and manufactured for use as internal components
of equipment.
Install the motor and driver in a well-ventilated place where they can be inspected
easily and the following conditions are satisfied:
• Inside an enclosure that is installed indoors (provide vent holes)
• Operating ambient temperature: 0 to +50 °C (+32 to +122 °F) (non-freezing)
• Operating ambient humidity: 85% or less (non-condensing)
• Area that is free of explosive atmosphere or toxic gas (such as sulfuric gas) or
liquid
• Area not exposed to direct sun
• Area free of excessive amount of dust, iron particles or the like
• Area not subject to splashing water (rains, water droplets), oil (oil droplets) or
other liquids
• Area free of excessive salt
• Area not subject to continuous vibration or excessive shocks
• Area free of excessive electromagnetic noise (from welders, power machinery,
etc.)
• Area free of radioactive materials, magnetic fields or vacuum
Install the motor to a flat mounting plate offering excellent vibration resistance and
high heat conductivity.
