4 Preparation
−8−
4 Preparation
The following describes the items to be confirmed, names and functions of
individual components.
4.1 Checking the product
Open the package and make sure that the following items are supplied.
The supplied items vary depending on the product. If there is any shortage or
damage, contact the sales office where you bought the product.
The unit model of the product you bought should be checked by reference to the
model on the label of the package.
Check the models of the motor, gearhead and driver by reference to the models on
the name plate of each product.
Unit models for motor, gearhead and driver combinations are listed in section 4.2
“Combination tables.”
Geared type, round shaft type and pinion shaft type
• Motor 1 unit (Geared type is motor with gearhead)
• Driver 1unit
• I/O signals cable [300 mm (12 in.)] 1 pc.
• Power supply cable [300 mm (12 in.)] 1 pc.
• Operating manual (This manual) 1 copy
Combination type parallel shaft gearhead
• Motor with gearhead 1 unit
• Parallel key 1 pc.
• Driver 1unit
• I/O signals cable [300 mm (12 in.)] 1 pc.
• Power supply cable [300 mm (12 in.)] 1 pc.
• Hexagonal socket head screw set (four each of screws, washers and nuts) 1 set
• Operating manual (This manual) 1 copy
Combination type hollow shaft flat gearhead
• Motor with gearhead 1 unit
• Parallel key 1 pc.
• Driver 1unit
• I/O signals cable [300 mm (12 in.)] 1 pc.
• Power supply cable [300 mm (12 in.)] 1 pc.
• Hexagonal socket head screw set (four each of screws, washers and nuts) 1 set
• Safety cover 1 pc.
• Safety cover mounting screws (M3) 2 pcs.
• Operating manual (This manual) 1 copy
