Oriental motor BLHD100K User Manual

4 Preparation
−9−
4.2 Combination tables

Geared type
The motor and gearhead are integrated. The combination of motor and gearhead
cannot be changed.
Components model
Unit model
Motor model Driver model
BLH015K- BLHM015K- BLHD15K
 in the model names indicates a number representing the gear ratio (5, 10, 15, 20,
30, 50 or 100).
 Combination type parallel shaft gearhead
The motor comes preassembled with a parallel shaft gearhead.
Components model
Unit model
∗
Motor model
∗
Gearhead model Driver model
BLH230KC- BLHM230KC-GFS GFS2G BLHD30K
BLH450KC- BLHM450KC-GFS GFS4G BLHD50K
BLH5100KC- BLHM5100KC-GFS GFS5G BLHD100K
 in the model names indicates a number representing the gear ratio (5, 10, 15, 20,
30, 50,100 or 200).
∗ For the lead wire type, “KC” of the unit model and motor model are replaced by “K”.
 Combination type hollow shaft flat gearhead
The motor comes preassembled with a hollow shaft flat gearhead.
Components model
Unit model
∗
Motor model
∗
Gearhead model Driver model
BLH230KC-FR BLHM230KC-GFS GFS2GFR BLHD30K
BLH450KC-FR BLHM450KC-GFS GFS4GFR BLHD50K
BLH5100KC-FR BLHM5100KC-GFS GFS5GFR BLHD100K
 in the model names indicates a number representing the gear ratio (5, 10, 15, 20,
30, 50,100 or 200).
∗ For the lead wire type, “KC” of the unit model and motor model are replaced by “K”.
