Owon TAO3000 Series User Manual

6.Communication with Android Device via Wi-Fi (Optional)
108
User Interface
Touch to enter
CH1
（Selected）
Voltage division of CH
(Touch to select CH, touch
again to turn CH on/off.)
Touch to
stop/continue to
synchronize with
the oscilloscope.
Time Base &
Horizontal
Position
Horizontal Position
Pointer
CH2
Show/hide
menu
(see below)
Trigger
Level
Share the image/wave file via
the installed sharing apps
Save into wave file
(bmp, png, bin, csv)
Exit APP
Submit feedback
Swipe from the left edge
of the screen to show the
trigger source menu
Trigger Source Menu
Trigger Source Menu
